DGF 2.0 FLEX HUB RSB X .94
This part number has been superseded by part number 398002.
Details
Coupling Size: 2
Coupling Component: Hub
Coupling Type: Metallic
Shaft Attachment: Rough Bore
Bore Diameter (Maximum): 3.0000 in
Angular Misalignment: 1.5000°
Parallel Misalignment: 0.0850 in
Horsepower Per 100 Rat: 50 hp
Rated Torque: 31500 in-lb
Maximum Speed: 5000 RPM
Maximum Temperature Rating: 250 ° F
Coupling Component: Hub
Coupling Type: Metallic
Shaft Attachment: Rough Bore
Bore Diameter (Maximum): 3.0000 in
Angular Misalignment: 1.5000°
Parallel Misalignment: 0.0850 in
Horsepower Per 100 Rat: 50 hp
Rated Torque: 31500 in-lb
Maximum Speed: 5000 RPM
Maximum Temperature Rating: 250 ° F
