P2B-SCM-207
Details
Housing Type: Two-Bolt Pillow Block
Housing Material: Cast Iron
Shaft Attachment: Setscrew
Shaft Diameter: 2.4375 in
Expansion Capability: Non-Expansion (Fixed)
Ball Bearing Series: 214 Series
Insert Material: Steel
Lubrication Type: Grease
Seal Type: Single-Lip Contact
Base to Center Height: 3.0000 in
Bolt to Bolt (Max): 8.5000 in
Bolt to Bolt (Min): 7.5000 in
Bore Length: 2.5400 in
Maximum Speed: 2000 RPM
Static Load Capacity: 9838 lbf
Housing Material: Cast Iron
Shaft Attachment: Setscrew
Shaft Diameter: 2.4375 in
Expansion Capability: Non-Expansion (Fixed)
Ball Bearing Series: 214 Series
Insert Material: Steel
Lubrication Type: Grease
Seal Type: Single-Lip Contact
Base to Center Height: 3.0000 in
Bolt to Bolt (Max): 8.5000 in
Bolt to Bolt (Min): 7.5000 in
Bore Length: 2.5400 in
Maximum Speed: 2000 RPM
Static Load Capacity: 9838 lbf
